■ Beryllium copper alloy and Aluminum bronze material
■ Injection, Non- sparking, Insulated
■ AC 1000V IEC 60900 standard
■ With VDE certificate
| Number | S mm | L mm | H mm | Be-Cu g | Al-Cu g |
| 6405-3 | 3 | 59 | 25 | 8 | 7 |
| 6405-4 | 4 | 65 | 30 | 10 | 8 |
| 6405-5 | 5 | 79 | 32 | 16 | 12 |
| 6405-6 | 6 | 85 | 37 | 25 | 20 |
| 6405-7 | 7 | 88 | 43 | 34 | 30 |
| 6405-8 | 8 | 92 | 44 | 50 | 45 |
| 6405-9 | 9 | 97 | 44 | 61 | 55 |
| 6405-10 | 10 | 110 | 45 | 82 | 70 |
| 6405-11 | 11 | 119 | 48 | 100 | 90 |
| 6405-12 | 12 | 130 | 52 | 145 | 130 |
