■ Beryllium copper alloy and Aluminum bronze material.
■ DIN838Standard.
■ Die forged.
■ Both ends generally fit the same size of bolts and nuts.
| Number | S1*S2 mm | L mm | Be–Cl g | Al–Cu g |
| 151A-1719 | 17*19 | 280 | 180 | 160 |
| 151A-1922 | 19*22 | 300 | 210 | 190 |
| 151A-1924 | 19*24 | 320 | 320 | 290 |
| 151A-2123 | 21*23 | 320 | 370 | 335 |
| 151A-2224 | 22*24 | 330 | 420 | 380 |
| 151A-2427 | 24*27 | 340 | 480 | 430 |
| 151A-2730 | 27*30 | 350 | 530 | 480 |
| 151A-3032 | 30*32 | 370 | 690 | 620 |
| 151A-3236 | 32*36 | 430 | 1000 | 910 |
| 151A-3641 | 36*41 | 470 | 1270 | 1150 |
| 151A-4146 | 41*46 | 500 | 1580 | 1430 |
| 151A-4650 | 46*50 | 525 | 1900 | 1720 |
| 151A-5055 | 50*55 | 550 | 2850 | 2580 |
