■ Aluminium Bronze Alloy and Beryllium Copper Alloy
■ QB/T2613.8-2005
■ Die Forged
■ Red Finish
| Number | L mm | Kmax mm | Be-Cu g | Al-Cu g | Q’ty Carton | Be-Cu Gw kg | Al-Cu Gw kg |
| 125B-1002 | 100 | 13 | 33 | 30 | / | / | / |
| 125B-1004 | 150 | 18 | 145 | 130 | 20 | 3.35 | 3.15 |
| 125B-1006 | 200 | 24 | 275 | 240 | 20 | 6.23 | 5.75 |
| 125B-1008 | 250 | 30 | 485 | 435 | 20 | 10.74 | 9.8 |
| 125B-1010 | 300 | 36 | 780 | 715 | 10 | 8.50 | 7.85 |
| 125B-1012 | 375 | 46 | 1400 | 1220 | 6 | 10.05 | 9.28 |
| 125B-1014 | 450 | 55 | 2150 | 1900 | 4 | 10.10 | 9.13 |
| 125B-1016 | 600 | 65 | 3500 | 3100 | / | / | / |
