■ Aluminium Bronze Alloy and Beryllium Copper Alloy
■ Die Forged
■ The Hexagon rod was locked with copper head
■ Replacable hexagon rod
| Number | C inch | S mm | L mm | Be—Cu g | Al-Cu g |
| 111A-1002 | 1/4 | 3 | 55 | 17 | 16 |
| 111A-1004 | 4 | 55 | 17 | 16 | |
| 111A-1006 | 5 | 55 | 20 | 18 | |
| 111A-1008 | 6 | 55 | 26 | 23 | |
| 111A-1010 | 7 | 55 | 30 | 27 | |
| 111A-1012 | 8 | 65 | 45 | 40 | |
| 111A-1014 | 9 | 65 | 55 | 50 | |
| 111A-1016 | 10 | 65 | 65 | 60 | |
| 111A-1018 | 1/2 | 12 | 60 | 125 | 110 |
| 111A-1020 | 13 | 60 | 135 | 120 | |
| 111A-1022 | 14 | 60 | 140 | 125 | |
| 111A-1024 | 15 | 60 | 165 | 145 | |
| 111A-1026 | 16 | 60 | 170 | 150 | |
| 111A-1028 | 17 | 60 | 175 | 160 | |
| 111A-1030 | 18 | 60 | 190 | 170 | |
| 111A-1032 | 19 | 62 | 220 | 200 | |
| 111A-1034 | 20 | 62 | 230 | 205 |
