■ Beryllium copper alloy and Aluminum bronze material
■ DIN3120 Standard.
■ Die forged.
■ It suitable for use where space is narrow or deep concavity to tighten or loosen bolts and nuts
| Number | S mm | mm | Be-Cu g | Al-Cug |
| 106-22 | 22 | 55 | 361 | 330 |
| 106-24 | 24 | 55 | 372 | 340 |
| 106-25 | 25 | 55 | 377 | 345 |
| 106-26 | 26 | 55 | 383 | 350 |
| 106-27 | 27 | 55 | 394 | 360 |
| 106-28 | 28 | 55 | 397 | 363 |
| 106-29 | 29 | 55 | 399 | 365 |
| 106-30 | 30 | 60 | 443 | 405 |
| 106-31 | 31 | 60 | 448 | 410 |
| 106-32 | 32 | 60 | 481 | 440 |
| 106-34 | 34 | 60 | 497 | 455 |
| 106-36 | 36 | 65 | 550 | 500 |
| 106-38 | 38 | 65 | 620 | 560 |
| 106-41 | 41 | 70 | 690 | 625 |
| 106-46 | 46 | 75 | 850 | 740 |
| 106-50 | 50 | 75 | 850 | 760 |
| 106-55 | 55 | 80 | 1160 | 1000 |
| 106-60 | 60 | 85 | 1390 | 1260 |
| 106-65 | 65 | 90 | 1750 | 1580 |
| 106-70 | 70 | 90 | 2150 | 1950 |
| 106-75 | 75 | 95 | 2680 | 2430 |
| 106-80 | 80 | 95 | 3080 | 2800 |
| Number | S | L | Bc-Cu | Al-Cu |
| inch | mm | g | g | |
| 106—1002 | 1-1/16 | 55 | 394 | 360 |
| 106—1004 | 1-1/8 | 55 | 398 | 364 |
| 106-1006 | 1-3/16 | 60 | 442 | 405 |
| 106-1008 | 1-1/4 | 60 | 470 | 431 |
| 106-1010 | 1-5/16 | 60 | 483 | 442 |
| 106-1012 | 1-3/8 | 60 | 490 | 448 |
| 106-1014 | 1-7/16 | 65 | 560 | 500 |
| 106-1016 | 1-1/2 | 65 | 620 | 560 |
| 106-1018 | 1-5/8 | 70 | 690 | 625 |
| 106-1020 | 1-7/8 | 75 | 850 | 740 |
| 106-1022 | 2 | 75 | 960 | 850 |
| 106-1024 | 2-1/4 | BO | 1250 | 1130 |
| 106-1026 | 2-1/2 | 90 | 1700 | 1550 |
| 106-1028 | 2-3/4 | 90 | 2050 | 1850 |
| 106-1030 | 3 | 95 | 2750 | 2500 |
